| Function: | Aluminum Window Making | Rotating Rate: | 3100r/min |
|---|---|---|---|
| Blade Size: | D=500mm | Cutting Scale: | 135x300mm |
| Cutting Length: | 400-4200mm | Cutting Angle: | 45, -45, 90 Degree |
| Input Power: | 4.4Kw | Product: | CNC Automatic Aluminum Window Making Machine Double Head Cutting Saw Machine |
| High Light: | aluminium profile cutting machine,aluminium windows cutting machine |
||
1. For cutting Aluminum profile.
2. The feeding system adopts imported linear guide pair, with high accuracy and stability.
3. Auto 45°and 90°cutting change
4. Imported linear guiding pair ensured steady processing accuracy.
5. Saw blade rotates smoothly due to high accuracy spindle.
6. Hydraulic feeding systems ensure precise and stable feeding.
7. Middle auto-induction profile supporter and following profile supporter make the loading and clamping convenient.
8. Carbide saw blade is of accurate processing and high efficiency.
9. Two heads can work together or single, when together work, one time can cut off the required length and angle
| Voltage | 380V/50HZ | |
| Power | 4.4KW | |
| Working parameters | Saw size | D=500mm d=30mm |
| Rotation rate | 2800r/min | |
| Air pressure | 0.5-0.8MPa | |
| Cutting scale | HxWxL (mm) | 135x300x(400-4200) |
1, Used for cutting of aluminum and PVC profiles;
2, CNC controlling system, achieve various profiles automatic cutting off;
3, Adopt airdraulic damping cylinder, ensure uniform speed feeding and smooth operation;
4, High accuracy main spindle and saw blade rotate smoothly;
5, Color touching display interface;
6, Feeding system adopts imported linear guide pair, with high accuracy and stability;
7, Optional 45°and 90°cutting;
8, Equipped with Japan imported blade;
